Description

This Practice defines the deliverables from the control valve vendor, manufacturer, or supplier and defines the minimum requirements for documentation, the valve body, testing, and inspection. In addition, the Control Valve Specification Sheet, included with this Practice, shall be used to communicate overall control valve requirements for a project.

The intention is that the project or site personnel complete this specification sheet for all the control valves for the project or site. This specification sheet allows the project or site personnel to customize requirements. This specification sheet is designed to reference other internal company or site requirement documents such as positive material identification. Individual control valve data sheets shall be filled out for each control valve to comply with the requirements of this Practice and with PIP PCCCV001 – Selection of Control Valves.

This Practice does not include requirements for motor-operated valves, on-off valves intended for emergency isolation, or valves with hydraulic actuators. Only general requirements are provided in this Practice. The individual requirements for each valve shall be included on the data sheet for each corresponding control valve (e.g., ISA20).

Product Details

Published:

03/01/2010

File Size:

1 file , 360 KB

Note:

This product is unavailable in Belarus, Russia, Ukraine

Description

This Practice describes the minimum general requirements for the control valve body construction, actuator, auxiliaries (e.g., positioner, limit switches, etc.), testing, inspection, and documentation. This Practice provides requirements for the format for providing data for each individual control valve, the method to be used for valve sizing, and other design considerations. For Control Valves sizing and selection see PIP PCCCV001 and PIP PCECV001.

This Practice does not include requirements for motor-operated valves, on-off valves intended for emergency isolation, and valves with hydraulic actuators. For On-Off Valves, see PIP PCCCV003, Remotely Actuated On-Off Valves Selection Criteria and PIP PCECV003, Guidelines for Application of Remotely Actuated On-Off Valves.

Product Details

Published:

08/01/2021

Number of Pages:

11

File Size:

1 file , 420 KB

Note:

This product is unavailable in Belarus, Russia, Ukraine

Description

This Practice describes the minimum general requirements for the control valve body construction, actuator, auxiliaries (e.g., positioner, limit switches, etc.), testing, inspection, anddocumentation. This Practice provides requirements for the format for providing data for each individual control valve, the method to be used for valve sizing, and other design considerations.For Control Valves sizing and selection see PIP PCCCV001 and PIP PCECV001.

This Practice does not include requirements for motor-operated valves, on-off valves intended for emergency isolation, and valves with hydraulic actuators. For On-Off Valves, see PIPPCCCV003, Remotely Actuated On-Off Valves Selection Criteria and PIP PCECV003, Guidelines for Application of Remotely Actuated On-Off Valves.

Product Details

Published:

03/01/2016

Number of Pages:

11

File Size:

1 file , 420 KB

Note:

This product is unavailable in Belarus, Russia, Ukraine
