SAE J647_201911

$42.50

Automatic Transmissions – Schematic Diagrams
standard by SAE International, 11/19/2019

Format: PDF      In Stock



Category:

NOTE: Our website provide PDF immediately download, sometimes when the payment is processed and you did not receive the file, please feel free to connect with us.

Description

The following schematic diagrams reflect various methods of illustrating automotive transmission arrangements. These have been developed to facilitate a clear understanding of the functional interrelations of the gearing, clutches, hydrodynamic drive unit, and other transmission components.

Two variations of transmission diagrams are used: in neutral (clutches not applied), and in gear. For illustrative purposes, some typical transmissions are shown.

Product Details

Published:
11/19/2019
File Size:
1 file , 370 KB
Redline File Size:
2 files , 3.2 MB
